Модель: 85150
Артикул: 23959
6 SLIM CHANNELS – DISCRETE OUTDOOR / INDOOR PROTECTION
Providing convenient wheelchair access the Defender® NANO cable protection system is the ultra low profile solution for a
wide range of indoor and outdoor applications. Available with black or yellow lid Defender
NANO protectors feature 6 chan-
nels for clean and tidy cable arrangement, T-shaped connectors and a 2 t per 20 x 20 cm load capacity to support lightweight
vehicles, carts and pedestrian traffic but also forklifts and pallet trucks thanks to their low height design. Male and female end
ramps are available to provide secure cable entry and exit.
The Defender
NANO protection system is ideal for carnivals, fairs, trade shows, exhibitions, shopping malls, warehouses,
stages, studios and broadcasting. Not suitable for road traffic.
The smallest unit, with great potential. Light, professional, wheelchair accessible and universally applicable.
With its' 6 channels the DEFENDER NANO meets all demands for a professional cable crossover in the smallest size.
Thanks to the addition of this compact, extremely light (approx. only 4kg!) and durable (including vehicle traffic) cable crossover, the DEFENDER Series of cable protectors is now complete in the compact sector.
Like all of the Defender series crossovers, the DEFENDER NANO is resistant to oils, acids, and petrol, and has a patented self-cleaning hinged closure. (EU Patent No.: EP1366550)
Легкий и профессиональный кроссовер наименьшего размера с большим потенциалом. Он широко применим и не станет преградой для инвалидных кресел. Благодаря появлению этого компактного, чрезвычайно легкого (всего около 4 кг!) и прочного кабельного кроссовера, серия DEFENDER дополнила линейку компактных кроссоверов.
Области применения:
Как и все кроссоверы серии Defender, Defender NANO является стойким к маслам, кислотам и бензину и имеет запатентованное самоочищающееся покрытие.
SPECIFICATIONS:
Art. No.: 85150
Product: 6-channel cable protector
Channel W x H: 17 x 18 mm (channels 1 to 6)
Material: TPU (Thermoplastic Polyurethane)
Shore A hardness: 88 ± 4
Load capacity: approx. 2 t / 20 x 20 cm (typical tyre footprint area)
Fire rating: B2 (B1 also available)
Resistant to: most acids, oils, gasoline
Operating temperature: -30° to +60° C
Length: 1.000 mm
Width: 280 mm
Height: 32 mm
Weight: 4.37 kg
DEFENDER® NANO End Ramp female
Art. No.: 85158F
DEFENDER® NANO End Ramp male
Art. No.: 85158M
